Anderic RR7099TKIT remote control, substitute for KUJCE10203 Ceiling Fan

Roll over image to zoom in Click on image to zoom

Anderic Substitute Kit for KUJCE10203 Ceiling Fan Remote Control [RR7099TKIT]

Name: Anderic Substitute Kit for KUJCE10203 Ceiling Fan Remote Control [RR7099TKIT]
Brand: Anderic
SKU: 277673-NEW
Price: 54.95 USD
Availability: InStock

Price:

$54.95

Stock:

In stock (327 units) | Same day shipping*

Quantity:

Key Features

Replaces your KUJCE10203 with a ceiling fan remote and receiver kit with a wall mount. Fan speed (Low, Medium, High) and light with dimming 20 to 100 percent.
To set it up in place of your KUJCE10203, remove the remote's battery cover and set the code (dip) switches up or down in a pattern of your choice. The factory setting is all up, then set the receiver's code switches to the same pattern, and replace the battery cover.
The kit includes the RR7099T remote, a UC7067FCRX receiver and a wall mount.
Fan speed (Low, Medium, High) and light with dimming 20 to 100 percent.
Takes 1 9-Volt battery, not included.

The Anderic RR7099TKIT is a substitute kit for the KUJCE10203 remote. It is a ceiling fan remote and receiver kit with a wall mount.

Specifications

Shipped kit: Anderic RR7099TKIT
Radio frequency (RF): 304 MHz
Battery: 1 9-Volt (not included)

Good to Know

Does not work with fans that use the KUJCE9201 system
The receiver must be installed in the fan
Key names and layout may differ from the original. Compare your original's buttons before ordering.
This is a kit that includes a receiver; the KUJCE10203 is a remote only.

Setup / Pairing

Turn the power to the fan off at the circuit breaker. Install the receiver in the fan canopy following the wiring instructions included with the kit, then restore power.
Remove the remote's battery cover: push firmly below the arrow and slide it off. Set the code switches before installing the battery, because on some models the battery covers the switch panel.
With a small screwdriver or pen tip, slide the 4 code (dip) switches up or down to a pattern of your choice. The factory setting is all up.
Set the 4 code switches on the fan's receiver to exactly the same pattern as the remote. The remote and receiver only work together when the patterns match.
Insert the battery (not included), matching the polarity marks, and replace the battery cover.
Test: press a fan speed key and the light key. The fan and light respond when the patterns match.
If you cannot reach the receiver: set the remote's switches to one of the 16 patterns, press a key to test, and if the fan does not respond, move to the next pattern. Repeat until the fan responds.
If the fan or light turns on and off by itself, another remote is interfering: set a new matching pattern on both the remote and the receiver.

What's in the Box

1 Anderic RR7099T remote and 1 UC7067FCRX receiver
Wall mount bracket
Battery not included

Compatible Models

KUJCE10203

Before ordering, check the model or part number printed on your old remote (usually on the back or inside the battery compartment) and compare it to this list.

Product help/documentation (if applicable): User Guide

Features:

Replaces your KUJCE10203 with a ceiling fan remote and receiver kit with a wall mount. Fan speed (Low, Medium, High) and light with dimming 20 to 100 percent.
To set it up in place of your KUJCE10203, remove the remote's battery cover and set the code (dip) switches up or down in a pattern of your choice. The factory setting is all up, then set the receiver's code switches to the same pattern, and replace the battery cover.
The kit includes the RR7099T remote, a UC7067FCRX receiver and a wall mount.
Fan speed (Low, Medium, High) and light with dimming 20 to 100 percent.
Takes 1 9-Volt battery, not included.

Part/Model Number: KUJCE10203 / KUJCE10203

Power Information: 1 9-Volt Required, Not Included

FCC ID (if applicable): KUJCE10203

Frequency (if applicable): 304.0 MHz

Compatible with models (if applicable): KUJCE10203, KUJCE9201, RC104L, 0276094, EAER52BRZ5LKRCI

5 stars: 2 (67%)
4 stars: 1 (33%)
3 stars: 0 (0%)
2 stars: 0 (0%)
1 star: 0 (0%)

This product has no reviews of its own. The merchant grouped it with related products, so the reviews shown are from across that group.

Fits, works - glad it's available. Makes a click sound when changing fan speeds.

Just as advertised. Easy to install and works perfectly

Both my fan and light quit working. A 15 minute change out had both working. All wires were labeled for easy installation.

Hi Jerald, we're thrilled to hear that our remote control helped you get your fan and light back up and running quickly! Thanks for sharing your positive experience.
