Description
The Anderic RR7080T / UC7058GM kit is a replacement remote and receiver for the Hampton Bay Miramar 60 in. ceiling fan.
Specifications
- Kit: Anderic RR7080T
- Radio frequency (RF)
- Battery: 1 9-Volt (not included)
Good to Know
- Use the receiver with the RR7080T remote supplied in this kit.
Setup / Pairing
- Turn off power to the fan at the circuit breaker.
- Remove the screws from the receiver cover on top of the motor housing, and remove any zip ties holding the wires.
- Loosen the clip screw holding the power and antenna wires if needed, cut the crimps on the receiver's blue and white wires, and disconnect the 9-pin connector.
- Remove the two screws holding the old receiver.
- Install the new UC7058GM receiver in reverse order, using wire nuts to join its blue and white wires to the fan's blue and white wires. Note the receiver's 4 dip-switch pattern.
- Remove the remote's battery cover and set its 4 dip switches to exactly the same pattern before inserting the battery (factory setting is all up).
- Insert the battery (not included), matching the polarity marks, and replace the cover.
- Restore power and test the fan speeds and light.
- If the fan or light turns on and off by itself, another remote is interfering: set a new matching pattern on both the remote and the receiver.
Safety: turn off power at the circuit breaker before opening the fan canopy or touching the receiver.
What's in the Box
- 1 remote and 1 receiver
- Battery not included
Compatible Models
- Hampton Bay Miramar 60 in. ceiling fans (UC7058GM receiver)
- Also works with: Hampton Bay AC374-WB Miramar 60 in. Ceiling Fan 458 242, Hampton Bay AC374-BN Miramar 60 in. Ceiling Fan 339-793, Hampton Bay AC374-WB Miramar 60 in. Ceiling Fan 133-715
Before ordering, check the model or part number printed on your old remote (usually on the back or inside the battery compartment) and compare it to this list.
Caractéristiques
Product help/documentation (if applicable): Installation Instructions
Features:
- Works with models such as Hampton Bay AC374-WB and AC374-BN Miramar 60 in. ceiling fans.
- Turn off power to the fan at the circuit breaker, then remove the screws from the receiver cover on top of the motor housing, and remove any zip ties holding the wires. Loosen the clip screw holding the power and antenna wires if needed, cut the crimps on the receiver's blue and white wires, and disconnect the 9-pin connector; step-by-step instructions are in the description.
- UC7058GM receiver with a 9-pin connector and blue/white light wires. RR7080T remote, the matching remote for this receiver.
- Remote and receiver pair by matching 4 dip switches (16 codes). REVERSE key on the RR7080T toggles fan direction and the UC7058GM has reversing built in.
- Takes 1 9-Volt battery, not included.
Part/Model Number: AND-RR7080T-UC7058GM-KIT / AND-RR7080T-UC7058GM-KIT
Power Information: 1 9-Volt Required, Not Included
FCC ID (if applicable): CHQ7080T
Frequency (if applicable): 303.921 MHz
Compatible with models (if applicable): UC7058GM, AC374-WB, AC374-BN, 339-793, 133-715
